Personnel Computers and Single-Processor Systems

Figure 2.20: IBM PC XT.

• Single-user, dedicated. Previously thought as individuals have sole use of computer, do not need advanced CPU utilization, protection features (see Fig. 2.20).
• Not still true. May run several different types of OS (Windows, Mac OS X, UNIX, Linux) which offer multitasking and virtual memory on PC hardware.
• Most systems use a single processor. On a single-processor system, there is one main CPU capable of executing a general-purpose instruction set, including instructions from user processes. Almost all systems have other special-purpose processors as well.
• They may come in the form of device-specific processors, such as disk, keyboard, and graphics controllers; or, on mainframes, they may come in the form of more general-purpose processors, such as I/O processors that move data rapidly among the components of the system.
• All of these special-purpose processors run a limited instruction set and do not run user processes. Sometimes they are managed by the OS, in that the OS sends them information about their next task and monitors their status.
• For example, a disk-controller microprocessor receives a sequence of requests from the main CPU and implements its own disk queue and scheduling algorithm. This arrangement relieves the main CPU of the overhead of disk scheduling.
• PCs contain a microprocessor in the keyboard to convert the keystrokes into codes to be sent to the CPU.
• The use of special-purpose microprocessors is common and does not turn a single-processor system into a multiprocessor. If there is only one general-purpose CPU, then the system is a single-processor system.
