Condition Variables for Synchronization

• Indiscriminate use of locks can result in idling overhead from blocked threads.
• While the function pthread_mutex_trylock removes this overhead, it introduces the overhead of polling for availability of locks.
• For example, if the producer-consumer example is rewritten using pthread_mutex_trylock instead of pthread_mutex_lock,
• the producer and consumer threads would have to periodically poll for availability of lock (and subsequently availability of buffer space or tasks on queue).
• A natural solution to this problem is to suspend the execution of the polling thread until space becomes available.
• An interrupt driven mechanism as opposed to a polled mechanism.

• The availability of space is signaled by the thread that holding the space.
• The functionality to accomplish this is provided by a condition variable.
• A condition variable is a data object used for synchronizing threads and always used in conjunction with a mutex lock.
• While mutexes implement synchronization by controlling thread access to data,
• condition variables allow threads to synchronize based upon the actual value of data.
• This variable allows a thread to block itself until specified data reaches a predefined state.

• pthread_cond_wait


• A thread locks this mutex and tests the predicate defined on the shared variable;
• if the predicate is not true, the thread waits on the condition variable associated with the predicate using this function.
• A call to this function blocks the execution of the thread until it receives a signal from another thread or is interrupted by an OS signal.
• In addition to blocking the thread, the pthread_cond_wait function releases the lock on mutex.
• This is important because otherwise no other thread will be able to work on the shared variable and the predicate would never be satisfied.

• pthread_cond_signal


• When the condition is signaled, pthread_cond_signal, one of these threads in the queue is unblocked,
• and when the mutex becomes available, it is handed to this thread (and the thread becomes runnable).
• When the thread is released on a signal, it waits to reacquire the lock on mutex before resuming execution.
• It is convenient to think of each condition variable as being associated with a queue.
• Threads performing a condition wait on the variable relinquish their lock and enter the queue.

 $&bull#bullet;$

pthread_cond_init & pthread_cond_destroy

 $&bull#bullet;$

Function calls for initializing and destroying condition variables.

 $&bull#bullet;$

Condition variables must be declared with type pthread_cond_t, and must be initialized before they can be used.

 $&bull#bullet;$

There are two ways to initialize a condition variable:

1

Statically, when it is declared. For example: pthread_cond_t myconvar = PTHREAD_COND_INITIALIZER;

2

Dynamically, with the pthread_cond_init() routine.

• The function pthread_cond_init initializes a condition variable (pointed to by cond).
• The ID of the created condition variable is returned to the calling thread through the condition parameter.
• This method permits setting condition variable object attributes, attr. (NULL assigns default attributes)
• If at some point in a program a condition variable is no longer required, it can be discarded using the function pthread_cond_destroy.

Figure 6.8: A representative sequence for using condition variables.

• When a thread performs a condition wait, it takes itself off the runnable list consequently, it does not use any CPU cycles until it is woken up.
• This is in contrast to a mutex lock which consumes CPU cycles as it polls for the lock.
• pthread_cond_broadcast.


• In some cases, it may be beneficial to wake all threads that are waiting on the condition variable as opposed to a single thread.
• An example of this is in the producer-consumer scenario with large work queues and multiple tasks being inserted into the work queue on each insertion cycle.
• Another example is in the implementation of barriers.

• pthread_cond_timedwait,


• It is often useful to build time-outs into condition waits.
• Using the function a thread can perform a wait on a condition variable until a specified time expires.
• At this point, the thread wakes up by itself if it does not receive a signal or a broadcast.
• If the absolute time abstime specified expires before a signal or broadcast is received, the function returns an error message.
• It also reacquires the lock on mutex when it becomes available.
